VESC 6 HP - HIGH POWER PCB - The next generation - Benjamin Vedder Electronic Speed Controller

VESC 6 HP - HIGH POWER PCB - The next generation - Benjamin Vedder Electronic Speed Controller VESC 6 HP - HIGH POWER PCB - The next generation - Benjamin Vedder Electronic Speed Controller BLACK 1036 Strand 4mm core Silicon Coated Cable with WHITE TRAMPA Logo - priced per 10cm XT90PB-F connector - Female XT90s Anti Spark Connector - Female
RRP
£275+

Features

- Current and voltage measurement on all phases (three phase shunts)
- Adjustable current and voltage filters
- built in IMU chip (accelerometer, gyro)
- Regenerative braking
- Traction control (single and twin setup)
- Sensored or sensor less operation + hybrid mode, HFI and sildent HFI
- 100% torque from 0 RPM without sensors (for most salient BLDC motors)
- highly accurate sensorless position control (for most salient BLDC motors)
- Configurable RPM-, current-, voltage- and power limits
- Input source: PPM, Analog, NRF Nyko Kama Nunchuck
- Communication ports: USB, CAN,UAVCAN, UART
- Throttle curve and ramping for all input sources
- Separate throttle curves for acceleration and brakes
- Seamless 4-quadrant operation
- Motor revolution, amp hour, watt hour counting
- Display of speed, power, duty cycle, amp flow, estimated range and battery status on App
- Accumulated data from arrays of VESCs
- Real time data analysis and read out via communication ports
- Real time data analysis and read out via VESC-Tool APP or VESC-Tool software
- Adjustable protection against:

          -    Low input voltage
          -    High input voltage
          -    High motor current
          -    High input current
          -    High regenerative braking current (separate limits for the motor and the input)
          -    High RPM (separate limits for each direction).
          -    Over temperature (MOSFET and motor)

Technical Data Sheet

- Voltage: 11.1V – 60V (Safe for 3S to 12S LiIon/LiPo).
- Voltage spikes may not exceed 60V! 52V max input voltage.
- Current: Continuous 70-100A, Motor current max 160A, Spikes 210A.  Values depend on the temperature and air circulation around the device!
- 5V 1A output for external electronics
- 3.3V 0,5A output for external electronics
- Modes: DC, BLDC, FOC (sinusoidal)
- Supported sensors: ABI, HALL, AS5047



BLACK 1036 Strand 4mm core Silicon Coated Cable with WHITE TRAMPA Logo - priced per 10cm

Allow your Electric board to gain the maximum performance by only fitting the very highest quality Electrical Cables & Connectors to let the power in your battery flood out as performance at the wheel!! Its taken a serious wedge of cash to get what we wanted & a hell of a long time waiting for our turn to produce to such a small amount of cable at such a high quality standard, but finally TRAMPA has got what it wanted & has now taken delivery of its own Super high Quality Silicon Cables in RED & BLACK with contrasting Black & White TRAMPA logos to prove the quality & show off the kind of performance your board is harvesting! :-)

TRAMPA's Gorgeous Silicon cables are made by the same GERMAN company who makes the world Famous BLAFF Cables. BLAFF cable is used for highest demanding jobs where performance is critical. BLAFF's Cables are so good they are used for public Transportation and the likes (Trains, Trams, Planes) as they have a global reputation of incredible high standards.

Enclosed in the Besilen insulated​ Silicon Outer lies 1800 Highly flexible TOP QUALITY Copper strands in the center...

BLACK Silicon Casing with contrasting WHITE TRAMPA logo's
Copper Core Dimension - 4mm
Outer Casing Dimension - 4.7mm
Temperature Range -
- Flexible use -25ºC / +180ºC
- Fixed laying -40ºC / +180ºC
Normal Voltage Uo/U 300/300V
Copper used weight 38.4kg per 1000 meters = 3.84 grams per centimeter + casing

BLACK 1036 Strand 4mm core Silicon Coated Cable with WHITE TRAMPA Logo - priced per 10cm

Allow your Electric board to gain the maximum performance by only fitting the very highest quality Electrical Cables & Connectors to let the power in your battery flood out as performance at the wheel!! Its taken a serious wedge of cash to get what we wanted & a hell of a long time waiting for our turn to produce to such a small amount of cable at such a high quality standard, but finally TRAMPA has got what it wanted & has now taken delivery of its own Super high Quality Silicon Cables in RED & BLACK with contrasting Black & White TRAMPA logos to prove the quality & show off the kind of performance your board is harvesting! :-)

TRAMPA's Gorgeous Silicon cables are made by the same GERMAN company who makes the world Famous BLAFF Cables. BLAFF cable is used for highest demanding jobs where performance is critical. BLAFF's Cables are so good they are used for public Transportation and the likes (Trains, Trams, Planes) as they have a global reputation of incredible high standards.

Enclosed in the Besilen insulated​ Silicon Outer lies 1800 Highly flexible TOP QUALITY Copper strands in the center...

BLACK Silicon Casing with contrasting WHITE TRAMPA logo's
Copper Core Dimension - 4mm
Outer Casing Dimension - 4.7mm
Temperature Range -
- Flexible use -25ºC / +180ºC
- Fixed laying -40ºC / +180ºC
Normal Voltage Uo/U 300/300V
Copper used weight 38.4kg per 1000 meters = 3.84 grams per centimeter + casing

XT90PB-F connector - Female

On most TRAMPA electrical components, you’ll find AMASS XT90 connectors.  With a strong nylon plastic body & cylindrical brass contacts that comfortably fit 10-12 gauge wires, XT90 connectors are rated to handle 90 Amps continuous – but have been tested up to 270A!

Available as standard, or Anti-Spark - we recommend Anti-Spark for connections that are likely to be plugged/unplugged often.

XT90s Anti Spark Connector - Female

On most TRAMPA electrical components, you’ll find AMASS XT90 connectors.  With a strong nylon plastic body & cylindrical brass contacts that comfortably fit 10-12 gauge wires, XT90 connectors are rated to handle 90 Amps continuous – but have been tested up to 270A!

Available as standard, or Anti-Spark - we recommend Anti-Spark for connections that are likely to be plugged/unplugged often.

VESC 6 HP - HIGH POWER PCB - The next generation - Benjamin Vedder Electronic Speed Controller

Introducing the amazing VESC® 6 MKVI HP (Higher Power) Speed Controller, the sixth major product update of the world famous VESC 6 motor controller with some extra punch on the top end. Packed with a variety of amazing new features, this VESC motor controller is certainly worthy of its pimpin’ gold logo, pushing up to 160A burst reliably towards your motor + allowing spikes to surpass 200A. This device is ideal for those who need a lot of power for a short period of time - perfect for Hydorfoils and other demanding applications.

The second VESC controller capable of hibernating, your board can conserve power while not in use - reducing power consumption to just 20μA – less than the self-discharge rate of the batteries. Or with automatic power off, your VESC controller can switch itself off after a set amount of time.

No more loop keys! Compatible with power buttons / switches, the VESC 6 MKVI controller can be ready to go with a single press / flick. If desired, multiple devices can share a single button.

Roll-to-start – it’s possible to set your board to power up with a small kick/nudge! The MK VI iteration now allows you to disable this feature.

In its development, no Mosfet switches were used - due to their tendency to eventually blow up one day. This saves on the additional costs of replacing them, & also adds to the longevity of the VESC 6 MKVI.

When we developed the VESC 75/300 controller, it was obvious that most of its features would be handy to have in the VESC 6 controller format.  As a result, Benjamin Vedder took on the challenge and re-designed the entire PCB of the VESC 6 controller, to make new, powerful features available in a smaller & cheaper 60V rated package.

The VESC 6 MKVI controller features THREE PHASE SHUNTS & adjustable CURRENT / VOLTAGE FILTERS - detecting any motor attached more precisely and reliably than ever before. Consequently all kinds of motors now run as smooth as butter & react PERFECTLY LINEAR to throttle input commands.

You’ll also find an IMU chip fitted - featuring a gyroscope, accelerometers the VESC 6MKVI knows its 3D orientation in space, 3 axis acceleration values.

UAVCAN has been added to the firmware allowing to interact with commonly used flight controllers like the PIXHAWK ®* devices. An incredible 12,000 lines of code have been added for the new hardware releases. To make the VESC controller nearly indestructible, the low voltage rails were redesigned A-Z.

VESC-Tool software is now available as an Android™ and iOS™ compatible App, allowing you to configure your VESC or VESC controller array with only a few clicks. User specific PROFILES will let you change in between different setups with a single tap on the fly.

Using an original VESC 6 MKVI controllermotor detection is now more precise than ever. Extreme low inductance (0.5 μHmotors are no issue!

Parameters for gearing and wheel diameter have been added, allowing display of speed, Wh usage per distance travelled, precise battery indicator, current consumption, duty cycle and power. Beautiful self-adjusting analogue displays make the readings of all parameters very enjoyable.

What makes the original VESC hardware so special?

The original hardware is perfectly matched to work seamless withe VESC-Tool software code. Both, hardware and software, have been designed by the same engineer, knowing all critical detail.

TRAMPA BOARDS LTD has teamed up with the internationally renowned 'YODA of electronics' (Benjamin Vedder) to bring to the world the most advance electronic speed controllers ever to be produced! Benjamin's family name is Vedder & the V in the brand VESC represents this. VEDDERs Electronic Speed Controller! There have been many ESC's before, but now the VESC line of products officially exists, made to work seamless with the latest software developments. Benjamin is globally renowned for his incredible electronics and software skills. He has worked tirelessly for well over 7 years fine tuning preceding versions of the globally famous & Trade Marked VESC products & after teaming up with TRAMPA BOARDS Ltd the development of the VESC product line has taken him to his highest capability yet.

The TRAMPA VESC controllers  comes fitted as standard with TRAMPA's very own & very special Silicone Coated & TRAMPA logo'd cables which are made up of 1036 Strands of Highly Flexible Top quality German copper. These quality details ensure the maximum performance at all times. Attached To the premium copper cables are genuine Amass XT90s connectors one side & 4mm Gold Plated Bullet connectors the other. The VESC 6 MKIII is installed with a custom moulded Internal Silicone Seal & is neatly fitted into the Heat sink which is a Solid Block of CNC'd  6061T6  Aluminum, used for dispensing the heat and offering maximum protection, allowing easy fitting and maximum good looks!..

The VESC line of produces are the most powerful & impressive Electric Speed Controller Benjamin has ever envisioned! They are  arguably by far the best and most versatile Electronic Speed Controllers the world has ever seen!! E Boarding, E-Biking, Remote control of all kinds including Drones & Robotics and Camera equipment (as well as thousands of industrial & recreational applications) are all about to be revolutionized by using the VESC series of products that will all come to the market soon...

Using the a VESC controller in your TRAMPA BOARD setup (Regardless of which model) will allow you to add any battery up to 12s with 60V of peak voltage. This is the perfect limit to give you incredible performance from your electric TRAMPA motors or similar. Using the new VESC TOOL software, you will be able to fine tune your performances relevant to your application, where you will be able to calculate your top end speeds & approx distance to travel using different combinations of power & gearing settings. Beautiful!

VESC controllers comes to you ready to plug in & go! They are delivered to you in a very stylish precision cut 6061 T6 aluminum heat-sink housing which has the TRAMPA & VESC logo beautifully laser etched to its surface & for further splash proofing we have invested into another mould for additional exterior Silicone Sealing which is available as an accessory to purchase.

The performance of the TRAMPA VESC controllers, compared to preceding third party models, is light years ahead! This is demonstrated in the cost as cheap non effective clones are sold according to their price not their quality. If you want the best performance then stick to the original hardware source - it will save you a lot of money on the long run and is a guarantee for ultimate performance and max compatibility with future software releases.

Our VESC controllers are being configured with the brand new Open Source, GPL V3 licensed VESC®-Tool Software:  www.vesc-project.com and on the Google Play Store™*.
The Open source, GPL V3 licensed VESC Firmware will come pre-installed on the device, allowing us to do extra testing of the device, prior to shipping.
This is the GPL V3 license contract for your reference:  www.vesc-project.com/GPL V3

Features

- Current and voltage measurement on all phases (three phase shunts)
- Adjustable current and voltage filters
- built in IMU chip (accelerometer, gyro)
- Regenerative braking
- Traction control (single and twin setup)
- Sensored or sensor less operation + hybrid mode, HFI and sildent HFI
- 100% torque from 0 RPM without sensors (for most salient BLDC motors)
- highly accurate sensorless position control (for most salient BLDC motors)
- Configurable RPM-, current-, voltage- and power limits
- Input source: PPM, Analog, NRF Nyko Kama Nunchuck
- Communication ports: USB, CAN,UAVCAN, UART
- Throttle curve and ramping for all input sources
- Separate throttle curves for acceleration and brakes
- Seamless 4-quadrant operation
- Motor revolution, amp hour, watt hour counting
- Display of speed, power, duty cycle, amp flow, estimated range and battery status on App
- Accumulated data from arrays of VESCs
- Real time data analysis and read out via communication ports
- Real time data analysis and read out via VESC-Tool APP or VESC-Tool software
- Adjustable protection against:

          -    Low input voltage
          -    High input voltage
          -    High motor current
          -    High input current
          -    High regenerative braking current (separate limits for the motor and the input)
          -    High RPM (separate limits for each direction).
          -    Over temperature (MOSFET and motor)

Technical Data Sheet

- Voltage: 11.1V – 60V (Safe for 3S to 12S LiPo).
- Voltage spikes may not exceed 60V!
- Current: Continuous 80A, Motor current max 160A, Spikes 210A.  Values depend on the temperature and air circulation around the device!
- 5V 1A output for external electronics
- 3.3V 0,5A output for external electronics
- Modes: DC, BLDC, FOC (sinusoidal)
- Supported sensors: ABI, HALL, AS5047

* Android is a trademark of Google LLC.
Google and Play Store are trademarks of Google LLC.
iOS is a registered trademark owned by Apple Inc.
PIXHAWK is a trademark of Lorenz Meier

****Introducing the amazing VESC® 6 MKVI HP (Higher Power) Speed Controller, the sixth major product update of the world famous VESC 6 motor controller with some extra punch on the top end. Packed with a variety of amazing new features, this VESC motor controller is certainly worthy of its pimpin’ gold logo, pushing up to 160A burst reliably towards your motor + allowing spikes to surpass 200A. This device is ideal for those who need a lot of power for a short period of time - perfect for Hydorfoils and other demanding applications.

The second VESC controller capable of hibernating, your board can conserve power while not in use - reducing power consumption to just 20μA – less than the self-discharge rate of the batteries. Or with automatic power off, your VESC controller can switch itself off after a set amount of time.

No more loop keys! Compatible with power buttons / switches, the VESC 6 MKVI controller can be ready to go with a single press / flick. If desired, multiple devices can share a single button.

Roll-to-start – it’s possible to set your board to power up with a small kick/nudge! The MK VI iteration now allows you to disable this feature.

In its development, no Mosfet switches were used - due to their tendency to eventually blow up one day. This saves on the additional costs of replacing them, & also adds to the longevity of the VESC 6 MKVI.

When we developed the VESC 75/300 controller, it was obvious that most of its features would be handy to have in the VESC 6 controller format.  As a result, Benjamin Vedder took on the challenge and re-designed the entire PCB of the VESC 6 controller, to make new, powerful features available in a smaller & cheaper 60V rated package.

The VESC 6 MKVI controller features THREE PHASE SHUNTS & adjustable CURRENT / VOLTAGE FILTERS - detecting any motor attached more precisely and reliably than ever before. Consequently all kinds of motors now run as smooth as butter & react PERFECTLY LINEAR to throttle input commands.

You’ll also find an IMU chip fitted - featuring a gyroscope, accelerometers the VESC 6MKVI knows its 3D orientation in space, 3 axis acceleration values.

UAVCAN has been added to the firmware allowing to interact with commonly used flight controllers like the PIXHAWK ®* devices. An incredible 12,000 lines of code have been added for the new hardware releases. To make the VESC controller nearly indestructible, the low voltage rails were redesigned A-Z.

VESC-Tool software is now available as an Android™ and iOS™ compatible App, allowing you to configure your VESC or VESC controller array with only a few clicks. User specific PROFILES will let you change in between different setups with a single tap on the fly.

Using an original VESC 6 MKVI controllermotor detection is now more precise than ever. Extreme low inductance (0.5 μHmotors are no issue!

Parameters for gearing and wheel diameter have been added, allowing display of speed, Wh usage per distance travelled, precise battery indicator, current consumption, duty cycle and power. Beautiful self-adjusting analogue displays make the readings of all parameters very enjoyable.

What makes the original VESC hardware so special?

The original hardware is perfectly matched to work seamless withe VESC-Tool software code. Both, hardware and software, have been designed by the same engineer, knowing all critical detail.

TRAMPA BOARDS LTD has teamed up with the internationally renowned 'YODA of electronics' (Benjamin Vedder) to bring to the world the most advance electronic speed controllers ever to be produced! Benjamin's family name is Vedder & the V in the brand VESC represents this. VEDDERs Electronic Speed Controller! There have been many ESC's before, but now the VESC line of products officially exists, made to work seamless with the latest software developments. Benjamin is globally renowned for his incredible electronics and software skills. He has worked tirelessly for well over 7 years fine tuning preceding versions of the globally famous & Trade Marked VESC products & after teaming up with TRAMPA BOARDS Ltd the development of the VESC product line has taken him to his highest capability yet.

The TRAMPA VESC controllers  comes fitted as standard with TRAMPA's very own & very special Silicone Coated & TRAMPA logo'd cables which are made up of 1036 Strands of Highly Flexible Top quality German copper. These quality details ensure the maximum performance at all times. Attached To the premium copper cables are genuine Amass XT90s connectors one side & 4mm Gold Plated Bullet connectors the other. The VESC 6 MKIII is installed with a custom moulded Internal Silicone Seal & is neatly fitted into the Heat sink which is a Solid Block of CNC'd  6061T6  Aluminum, used for dispensing the heat and offering maximum protection, allowing easy fitting and maximum good looks!..

The VESC line of produces are the most powerful & impressive Electric Speed Controller Benjamin has ever envisioned! They are  arguably by far the best and most versatile Electronic Speed Controllers the world has ever seen!! E Boarding, E-Biking, Remote control of all kinds including Drones & Robotics and Camera equipment (as well as thousands of industrial & recreational applications) are all about to be revolutionized by using the VESC series of products that will all come to the market soon...

Using the a VESC controller in your TRAMPA BOARD setup (Regardless of which model) will allow you to add any battery up to 12s with 60V of peak voltage. This is the perfect limit to give you incredible performance from your electric TRAMPA motors or similar. Using the new VESC TOOL software, you will be able to fine tune your performances relevant to your application, where you will be able to calculate your top end speeds & approx distance to travel using different combinations of power & gearing settings. Beautiful!

VESC controllers comes to you ready to plug in & go! They are delivered to you in a very stylish precision cut 6061 T6 aluminum heat-sink housing which has the TRAMPA & VESC logo beautifully laser etched to its surface & for further splash proofing we have invested into another mould for additional exterior Silicone Sealing which is available as an accessory to purchase.

The performance of the TRAMPA VESC controllers, compared to preceding third party models, is light years ahead! This is demonstrated in the cost as cheap non effective clones are sold according to their price not their quality. If you want the best performance then stick to the original hardware source - it will save you a lot of money on the long run and is a guarantee for ultimate performance and max compatibility with future software releases.

Our VESC controllers are being configured with the brand new Open Source, GPL V3 licensed VESC®-Tool Software:  www.vesc-project.com and on the Google Play Store™*.
The Open source, GPL V3 licensed VESC Firmware will come pre-installed on the device, allowing us to do extra testing of the device, prior to shipping.
This is the GPL V3 license contract for your reference:  www.vesc-project.com/GPL V3

Features

- Current and voltage measurement on all phases (three phase shunts)
- Adjustable current and voltage filters
- built in IMU chip (accelerometer, gyro)
- Regenerative braking
- Traction control (single and twin setup)
- Sensored or sensor less operation + hybrid mode, HFI and sildent HFI
- 100% torque from 0 RPM without sensors (for most salient BLDC motors)
- highly accurate sensorless position control (for most salient BLDC motors)
- Configurable RPM-, current-, voltage- and power limits
- Input source: PPM, Analog, NRF Nyko Kama Nunchuck
- Communication ports: USB, CAN,UAVCAN, UART
- Throttle curve and ramping for all input sources
- Separate throttle curves for acceleration and brakes
- Seamless 4-quadrant operation
- Motor revolution, amp hour, watt hour counting
- Display of speed, power, duty cycle, amp flow, estimated range and battery status on App
- Accumulated data from arrays of VESCs
- Real time data analysis and read out via communication ports
- Real time data analysis and read out via VESC-Tool APP or VESC-Tool software
- Adjustable protection against:

          -    Low input voltage
          -    High input voltage
          -    High motor current
          -    High input current
          -    High regenerative braking current (separate limits for the motor and the input)
          -    High RPM (separate limits for each direction).
          -    Over temperature (MOSFET and motor)

Technical Data Sheet

- Voltage: 11.1V – 60V (Safe for 3S to 12S LiPo).
- Voltage spikes may not exceed 60V!
- Current: Continuous 80A, Motor current max 160A, Spikes 210A.  Values depend on the temperature and air circulation around the device!
- 5V 1A output for external electronics
- 3.3V 0,5A output for external electronics
- Modes: DC, BLDC, FOC (sinusoidal)
- Supported sensors: ABI, HALL, AS5047

* Android is a trademark of Google LLC.
Google and Play Store are trademarks of Google LLC.
iOS is a registered trademark owned by Apple Inc.
PIXHAWK is a trademark of Lorenz Meier

With this VESC you get the following items
3x BLACK Silicon Coated Cable with WHITE TRAMPA Logo - per 10cm
6x BLACK Silicon Coated Cable with WHITE TRAMPA Logo - per 10cm
1x VESC 6 HP - HIGH POWER PCB
1x XT90PB-F connector - Female
1x XT90s Anti Spark Connector - Female
Weight: 90g

GOOD NEWS!!

Components we need to make the NEW Super Powerful VESC 6 HP will be delivered to the factory around the 17th October. This means we will be back in production very soon!!

All testing has been completed & we should be able to deliver to you in mid December 2022 if not before.

If you want to ensure you get one/some of these first, (there is limited supply) then please place your ADVANCED order as soon as you can to avoid delay or disappointment.

Please confirm you are aware this is an advance purchase & that your goods will not be received before the 1st of December 2022
Please confirm you are aware this is an advance purchase & that your goods will not be received before the 1st of December 2022

Yes im happy to sit out the wait for the goods to arrive

How many VESC 6 HP Do you want?
How many VESC 6 HP Do you want?

1x VESC 6 HP = £275+ Tax Each
1x VESC 6 HP = £275+ Tax Each

2x VESC 6 HP = £270+ Tax Each (+£265)
2x VESC 6 HP = £270+ Tax Each (+£265)

4x VESC 6 HP = £265+ Tax Each (+£785)
4x VESC 6 HP = £265+ Tax Each (+£785)

10x VESC 6 HP- £250 + Tax Each (+£2,225)
10x VESC 6 HP- £250 + Tax Each (+£2,225)

Quantity required:
We have enough parts to make…
RRP £275 - ADVANCE ORDERS ONLY

Excluding VAT

Approx price :
To see shipping prices delivered to your door please create an account and be logged into the system, so the system knows where you are and how much to quote you......

menu-icon menu-icon menu-icon menu-icon menu-icon menu-icon menu-icon menu-icon
