Weight: 0g

It used to be that when fitting the VESC HD-60T into the MONSTER Box, the 6 bulky motor cables took up a lot of space, so to save space we decided the best way to get around this would be to make a PCB based power converter, so we created the XT60 to XT90 PCB Power Adaptor.
Plugging in this little adaptor allows much more space in the box as the power runs through the PCB rather than bulky cables. A single XT90PB-M protrudes from the PCB allowing a simple battery Y Harness fitted with XT90s to prevent any accidents, to plug in & power both VESC in the HD-60T box!



Do you want a XT90 to XT60 PCB Based Power Adapter

Do you want a XT90 to XT60 PCB Based Power Adapter

---

XT90 to XT60 PCB Based POWER ADAPTOR (+£12.50) - OUT OF STOCK

---

NO Power Adapter Thanks

---

This product cannot be purchased on its own.
